RNA-6544

Intel N270 based Network Appliance

The RNA-6544’s industrial-graded fanless design along with its Quad 1Gb Ethernet device allows for maximum broad band throughput, networking flexibility, and sustainability in harsh environments. Equipped with the energy-efficient Intel Atom N270 and the EPC-6544 network device provides reliable operation 24/7 with low power consumption. The fanless eco-friendly quad Ethernet slot board creates network flexibility and maximum broad band throughput sustainable in harsh environments. The EPC-6544 network appliance offers solutions from home network firewalls, office networks, to VPN and industrial NVR applications.





Request Quote







RNA-6544
Model RNA-6544
Mainboard MIT-6542
Chipset Intel 945GSE Chipset
Processor Intel Atom N270 1.6 GHz
RAM 1x DDR2 SODIMM slots, support up to 2GB
Display Display Interface VGA of up to 2048×1536
Graphic Intel Integrated GMA950
Storage Optical –
HDD 2x 2.5” internal HDD/SSD bays, 2x SATA II port, 1 x EIDE
System I/0 PS/2 1x PS/2 Keyboard/mouse
COM 2x COM ports (1x Rear, 1x Internal via pin headers)
USB 4x internal USB 2.0, 2 x Rear USB 2.0
Audio HD Audio 5.1 Channel, 1x mic-in, 1x Line-in, 1x Line-out
LPT 1x internal LPT via pin header
Ethernet 4x 10/100/1000Mbps RJ45, Realtek RTL8111D
Expansion 1xPCI
System Control Power On/Off, Reset button
LED Indicator Power, HDD indicator
Noise Level fanless
Power consumption <15W at idle, <20W at 100% load (with 2.5” HDD and RAM installed)
Power Supply 60W 12V power adapter, 110V – 240V AC in
Cooling System fanless
OS Support Supports Windows Embedded, Windows XP, Windows 7, Vista & Linux
Mechanical & Environmental
Operation Temperature 0 ºC – 50 ºC (14ºF – 122 ºF)
Storage Temperature -40 ºC – 60 ºC (-40ºF – 140 ºF)
Relative Humidity 5%～95%, 40ºC, non-condensing
Vibration 0.5g rms/5~500Hz/ random operation
EMC CE/FCC Class B
Dimension 190 mm×215 mm×65 mm, 7.5” x 8.5” x 2.4” (W×D×H)
Net weight 3 lbs
Materials Steel
Coating Processes Power coating
Mounting Desktop
Color Black, custom color and branding available on OEM order
Part Number

Descriptions

Options
RNA-6544 Desktop fanless Quad GbE Mini ITX Barebone Server / NVR with Intel Atom N270 processor

–
CBL-PWUS US Power Cord

Included
CBL-PWUK UK Power Cord

Optional
RAM-1G-DDR3SODM 1G DDR3 SODIMM

Optional
RAM-2G-DDR3SODM 2G DDR3 SODIMM

Optional
HDD-80G-HDD25 80G SATA II 2.5″ Hard Drive

Optional
HDD-160G-HDD25 160G SATA II 2.5″ Hard Drive

Optional
HDD-250G-HDD25 250G SATA II 2.5″ Hard Drive

Optional
SSD-FTM16GL25H 16G SATA II 2.5″ SSD

Optional
SSD-FTM32GX25H 32G SATA II 2.5″ SSD

Optional
Data Sheet
RNA-6544
Drivers

Windows / Windows Embedded

Linux
INF Intel INF

–
VGA GMA 950

–
Audio ALC888

–
LAN Realtek RTL8111D
