RoughNUC-Plus

RNUCP-3SKB, Intel 6th Generation Core i3

The RoughNUC-Plus RNUCP-5SKB platform is equipped with Intel’s newest architecture, the 6^th generation Intel® Core™ i3-6100U processor. Performance, more efficient.  Intel® HD Graphic 520 with 4K display capabilities provides brilliant resolution for Digital Signage, Gaming and other GPU intense applications. RNUCP-5SYB has room for a 2.5” drive for additional storage and an M.2 SSD so you can transfer your data at lightning speed.

The RoughNUC-Plus chassis has a small footprint of 176.5mm x 200mm x 53.5mm and offers highly efficient conduction cooling, serving as both a case and passive (fan-less) heatsink for the Intel processor.  Systems are available in both commercial and extended operating temperatures and options for one or two additional Gigabit Ethernet ports.

Highlighted Features:

• 6^th Gen Processor:
  • Intel® Core™ i3-6100U Processor (2.3GHz Dual Core, 4MB Cache)
• GPUs:
  • Intel® HD Graphic 520
• Memory: up to 32GB DDR4 1.2V 2133MHz via 2x SODIMM slots
• Storage :2.5-inch HDD and/or M.2 SDD
• Display:
  • 1x Mini Display Port 1.2
  • 1x Full-size HDMI 1,4b
• Wireless:
  • Intel® Wireless-AC 8260 M.2 soldered-down IEEE 802.11ac
  • Bluetooth* 4.1
  • Intel® Wireless Display 6.0
• Networking
  • 1x Gigabit Ethernet port onboard
  • 1 or 2x Gigabit Ethernet expansion options
• Other I/O:
  • 3 to 4x USB 3.0
  • 2x internal header USB 2.0
  • Internal Audio headphone and mic jack (Intel HD Audio)
  • 1x internal header RS232 serial port (optional)
• Expansion Options
  • M.2 slot with PCIe X2 lanes + HS Custom Solutions Header with PCIe x4 lanes
• Wide Input Voltage range: 12-24V DC
• Other features — Table top, DIN Rail, Wall and VESA mountings
• Operating temperature: 0 to 60°C, -20 to 70°C available upon request
• Dimensions: 175.6mm x 200mm x 53.5mm (W x D x H)
• Operating system – Windows 7&8P, Ubuntu Linux, Microsoft WES8 and WES7

The I/O you need, with the processor you want!
