Project Description
RoughNUC-Plus, Intel Core i5
This RoughNUC-Plus system is designed around Intel’s Ivy Bridge microarchitecture with Core i5-3427U processors. They incorporate the Intel® Core™ vPro™ Technology, making them Hypervisor ready for embedded systems and allowing you to remotely manage or repair deployed systems. Best of all, RoughNUC-Plus systems provide the ability to do virtualization down at the core level with different operating systems running fully independent and fault tolerant of one another. This generation of core processors is feature rich with hyper threading Technology, HD 4000 Graphics, Security Technology, UEFI and Fast Boot BIOS, and much more.
RoughNUC-Plus systems offer the highest density of I/O connections in the embedded market today in an ultra-compact form factor. Up to three fully independent HD display ports, three Gigabit Ethernet ports, one USB 3.0 and two USB 2.o, a choice RS-232 or RS-485 ports, and two power input options are all available. Cadia Networks offers several standard configurations, but can customize the system’s I/O to meet the specific requirements of your application.
The RoughNUC-Plus chassis has a small footprint of 154mm x 150mm x 47mm and offers highly efficient conduction cooling, serving as both a case and passive (fan-less) heatsink for the Intel processor. Systems are available in both commercial and extended operating temperatures.
This new generation computing platforms provides flexible, customizable compute engines to drive digital signage, kiosks, video image capture, surveillance, HMI controllers, in-vehicle applications, command & control, industrial control, and intelligent computing for small spaces, or anywhere else you can imagine. The ruggedness of the RoughNUC-Plus make it ideal for a wide range of markets and applications including aerospace, oil exploration, mining, in-vehicle, defense, process control and many, many more.
RoughNUC-Plus Highlights:
Features and Configurations
Form factor
UCFF
Model Number
RNUCP-5RKE
BIOS ID string
RKPPT10H.86A
Processor
3rd generation Intel® Core™ i5 processor 3427U (soldered down)
Memory
Two SO-DIMM slots supporting up to 32 GB of 1333/1600MHz DDR-3 memory
Chipset
Intel® QS77 Express Chipset
Graphics
Dual Mini DisplayPort 1.1a portsHigh definition multimedia interface (HDMI) port supporting 1.4aSupporting triple independent display capability
Audio
Intel® High Definition Audio2 subsystem in the following configuration:8-channel (7.1) digital audio via HDMI 1.4a output and via one DisplayPort 1.1a connector
LAN support
Intel® Gigabit Ethernet controller
Peripheral interfaces
One USB 3.0 port (front panel)Two USB 2.0 ports (back panel)One RS232
Expansion capabilities
Full-sized mini PCI Express* (PCIe*) with mSATA supportHalf-sized mini PCIe
Part Number
Description
Barebones
RNUCP-5RKE
RoughNUC-Plus 5RKE, Conduction Cooled System, 2.8GHz Core i5-3427U Processor, 2 mPCIe slots, 1/3.0 USB, 2/2.0 USB, 1 GigE, Dual RS232 or 485, Dual Display Ports, 1 HDMI, Aux. Power Input & Reset
RNUCP-5RKE-2E2
RoughNUC-Plus 5RKE, Conduction Cooled System, 2.8GHz Core i5-3427U Processor, 2 mPCIe slots, 1/3.0 USB, 2/2.0 USB, 3 GigE, 1 RS232 or 485, Dual Display Ports, 1 HDMI, Aux. Power Input & Reset
Standard Development Kits other configurations available upon request
RNUCP-5RKE-DK-WIN8
RoughNUC-Plus Development Kit–i5, 4GB, 64GB SSD w/Licensed Windows 8 installed, 802.11n WiFi and Power Adapter
RNUCP-5RKE-DK-UNU
RoughNUC-Plus Development Kit–i5, 4GB, 64GB SSD w/Ubuntu installed, 802.11n WiFi and Power Adapter
RNUCP-5RKE-2E2-DK-WIN8
RoughNUC-Plus Development Kit–i5, 4GB, 64GB SSD w/Licensed Windows 8 installed, 802.11n and Power Adapter
RNUCP-5RKE-2E2-DK-UNU
RoughNUC-Plus Development Kit–i5, 4GB, 64GB SSD w/Ubuntu installed, 802.11n and Power Adapter
Integrated System 0 to +60C other configurations available upon request
RNUCP-5RKE-4-32
RoughNUC-Plus, i5, 4GB DDR3, 32GB SSD
RNUCP-5RKE-4-64
RoughNUC-Plus, i5, 4GB DDR3, 64GB SSD
RNUCP-5RKE-2E2-4-32
RoughNUC-Plus, i5, 2E2, 4GB DDR3, 32GB SSD
RNUCP-5RKE-2E2-4-64
RoughNUC-Plus, i5, 2E2, 4GB DDR3, 64GB SSD
Integrated System, Extended Operating Temp -20 to +70C other configurations available upon request
RNUCP-5RKE-4i-32i
RoughNUC-Plus, i5, 4GB DDR3, 32GB SSD
RNUCP-5RKE-4i-64i
RoughNUC-Plus, i5, 4GB DDR3, 64GB SSD
RNUCP-5RKE-2E2-4i-32i
RoughNUC-Plus, i5, 2E2, 4GB DDR3, 32GB SSD
RNUCP-5RKE-2E2-4i-64i
RoughNUC-Plus, i5, 2E2, 4GB DDR3, 64GB SSD
Pre-Installed Operating Systems
OS-WINXP
Licensed Windows XP Installed on SSD
OS-WIN7
Licensed Windows 7 Installed on SSD
OS-WIN8
Licensed Windows 8 Installed on SSD
OS-UBU
Ubuntu Installed on SSD
Accessories
CMPE-WIFIN
Mini-PCIe 802.11n WiFi module
RNUC-PA
RoughNUC-Plus Power Adapter with US plug
RNUCP-WM1
RoughNUC-Plus Wall-Mount Plate
MPEu-G2E
GPS Receiver Mini-PCIe Card
MPEu-K1E
Encrypted Flash Mini-PCIe Memory Card
HE910 PCIE
Mini-PCIe UMTS/HSPA
..Other I/O Expansion Options available in RoughNUC-Plus Chassis- Contact Us for Details
M303A-232
RS232 Adapter Card
M303A-485
RS485 Adapter Card
MPEe-A1E/A2E
Analog Input Mini-PCIe Card
MPEe-E3E
GigE Mini-PCIe Card
MPEe-U2E
Quad RS232/422/485 Serial + 12 GPIO lines Mini-PCIe Card
MPEs-S3E
Mini-PCIe Card SATA Adapter
MBU-67114x
2 Channel MIL-STD-1553/1760 Mini-PCIe Card
