RoughNUC-Plus Broadwell Front 1 45RoughNUC-Plus badge



RoughNUC-Plus systems are designed around a number of Intel’s “Next Unit of Computing” boards (NUC) ranging Bay Trail Atom & Celeron, Pentium, Haswell, Broadwell & Skylake Core i3, i5 & i7 processors.

Our third generation of RoughNUC-Plus platforms offers the I/O expansion you need with the processor you want beyond that of a standard NUCs. Expansion options include but not limited to  Gigabit Ethernet, USB 3.0, RS-232/485, CANBus, Frame Grabbers, etc. Cadia Networks offers several standard configurations, but can customize I/O to meet the specific requirements of your application.

The RoughNUC-Plus chassis has a small footprint of 150mm x 200mm x 47mm and offers highly efficient conduction cooling, RoughNUC-Plus Broadwell Front 2 45serving as both a case and passive (fan-less) heatsink for the Intel processor.  Systems are available in both commercial and extended operating temperatures.

These new generation computing platforms provides flexible, customizable compute engines to drive digital signage, kiosks, video image capture, surveillance, HMI controllers, in-vehicle applications, command & control, industrial control, and intelligent computing for small spaces, or anywhere else you can imagine. The ruggedness of the RoughNUC-Plus make it ideal for a wide range of markets and applications including aerospace, oil exploration, mining, in-vehicle, defense, process control and many other embedded applications.

Part Number Product Description
 RNUCP-3SYB  RoughNUC 3MYB: Conduction Cooled System, 6th Gen Intel Core i3-6100U Processor, 2 SODIMM slots up to 32GB, M.2 slot, WiFi 802.11ac onboard, 4x USB 3.0, GigE, Full-size HDMI, Display Port
RNUCP-3MYB RoughNUC 3MYB: Conduction Cooled System, 5th Gen Intel Core i3-5010U Processor, 2 SODIMM slots upto 16GB, 2 M.2 slots, 4x USB 3.0, GigE, Dual Display Port, Optional RS232
RNUCP-3MYB-S RoughNUC 3MYB: Conduction Cooled System, 5th Gen Intel Core i3-5010U Processor, 2 SODIMM slots upto 16GB, 2 M.2 slots, 4x USB 3.0, GigE, Dual Display Port, RS232
RNUCP-3MYB-E RoughNUC 3MYB: Conduction Cooled System, 5th Gen Intel Core i3-5010U Processor, 2 SODIMM slots upto 16GB, 2 M.2 slots, 4x USB 3.0, 2x GigE, Dual Display Port
RNUCP-3MYB-2E RoughNUC 3MYB: Conduction Cooled System, 5th Gen Intel Core i3-5010U Processor, 2 SODIMM slots upto 16GB, 2 M.2 slots, 4x USB 3.0, 3x GigE, Dual Display Port
RNUCP-3GKE-2E2 RoughNUC-Plus   3GKE: Conduction Cooled System, 1.80 GHz Intel Core i3-3217   Processor,   2 mPCIe slots, 3 USB, 3 GigE, Dual HDMI, RS232, Aux. Power Input & Reset
RNUCP-3CK-2E2 RoughNUC-Plus   3CK:   Conduction Cooled System, 1.80 GHz Intel Core i3-3217U Processor,   2 mPCIe slots, 3 USB, 3 GigE, Thunderbolt, 1 HDMI, RS232, Aux. Power Input   & Reset
Part Number Product Description
 RNUCP-5SYB  RoughNUC 5MYB: Conduction Cooled System, 6th Gen Intel Core i5-6260U Processor, 2 SODIMM slots up to 32GB, M.2 slot, WiFi 802.11ac onboard, 4x USB 3.0, GigE, Full-size HDMI, Display Port
RNUCP-5MYB RoughNUC 5MYB: Conduction Cooled System, 5th Gen Intel Core i5-5300U Processor, 2 SODIMM slots upto 16GB, 2 M.2 slots, 4x USB 3.0, GigE, Dual Display Port, vPro, Optional RS232
RNUCP-5MYB-S RoughNUC 5MYB: Conduction Cooled System, 5th Gen Intel Core i5-5300U Processor, 2 SODIMM slots upto 16GB, 2 M.2 slots, 4 USB 3.0, GigE, Dual Display Port, vPro, RS232
RNUCP-5MYB-E RoughNUC 5MYB: Conduction Cooled System, 5th Gen Intel Core i5-5300U Processor, 2 SODIMM slots upto 16GB, 2 M.2 slots, 4 USB 3.0, 2x GigE, Dual Display Port, vPro
RNUCP-5MYB-2E RoughNUC 5MYB: Conduction Cooled System, 5th Gen Intel Core i5-5300U Processor, 2 SODIMM slots upto 16GB, 2 M.2 slots, 3x USB 3.0, 3x GigE, Dual Display Port, vPro
RNUCP-5WYB-2E2 RoughNUC-Plus   5WYB, Conduction Cooled System, 2.6GHz 4th Gen Core i5-4250U Processor, 2   mPCIe slots, 4/3.0 USB, 2/2.0 USB, 3 GigE, Display Port, HDMI, Aux. Power   Input & Reset
RNUCP-5RKE-2E2 RoughNUC-Plus   5RKE, Conduction Cooled System, 2.8GHz Core i5-3427U Processor, 2 mPCIe   slots, 1/3.0 USB, 2/2.0 USB, 3 GigE, Dual Display Port, 1 HDMI, Aux. Power   Input & Reset
Part Number Product Description
RNUCP-BTC-2E2 RoughNUC-Plus   BTC  Conduction Cooled System, Bay Trail-M Quad Core Celeron N2930 7.5W, 2 mPCIe slots, 3 USB 2.0, 1 USB 3.0, Dual GigE, Dual HDMI, RS232/422/484
RNUCP-SKE-2E2 RoughNUC-Plus   SKE:   Conduction Cooled System, 1.10 GHz Intel Celeron 847E     Processor, 2 mPCIe slots, 3 USB, 3 GigE, Dual HDMI, RS232, Aux. Power Input   & Reset
  Call for release updates.

Call for release updates.

Call for release updates.
